Best ICF6 - Install Filters; Filter Installation (Ducted & Non-Ducted)

- 15 -
INSTALL FILTERS
DUCTED AND NON-DUCTED HOODS
1.To remove the GREASE filter, open the
perimeter panel (Fig.19).
2. Move the two retaining clips as showed in
Fig.20
3.Pull down the handle (Fig.21) to disengage
the grease filter. Pull down the wave filter
using the lateral handles (Fig.22) and see
page 5 for cleaning instructions.
NON-DUCTED HOODS
1. Non-ducted recirculation filters not
included. They must be purchased
separately (AFCICF6 Kit).
2. Remove the wave filter (Fig.22) using the
lateral handlings and engage the charcoal
filter as shown in Fig.23.
3. The charcoal filter replacement model is
AFCWC345.
Non-ducted recirculation filters
The non-ducted recirculation filters should
be changed every 6 months.
FIG. 20
FIG. 23FIG. 22
FIG. 21
FIG. 19
