Best K260A - Service Parts; Part Identification and Ordering

- 12 -
HL0024
15
14
16
20
19
18
17
11
5
9
13
7
12
6
8
1
2
3
4
10
MODEL K260A
17. SERVICE PARTS
* Standard Hardware - puchase locally. Order replacement parts by "PART NUMBER - not by "KEY NO".
‡ Not shown.
PA RT
NUMBER
V12969
V12970
V03241
V02544
V02264
V03255
V02772
V02773
V01869
V01582
V05520
V01964
V03462
V03461
V13220
V13221
V13112
V13222
V13322
V13323
Switch assembly, Black
Switch assembly, White
Chrome Ring
Halogen Lamp, PAR 20
Socket Lamp
Board Assembly
Female Connector
Male Connector
Machine Screw, #6-32 X 1/4"*
LockNut,6-32 *
Screw, #8-3/8, T/B* #8 Head
Screw, #6-1/2 T/A*
Grease Filter 9" x 12"
Grease Filter 11" x 12"
Grease Rail 30"
Grease Rail 36"
Grease Rail 42"
Grease Rail 48"
Grease Rail 54"
Grease Rail 60"
KEY
NO .
1
2
3
4
5
6
7
8
9
10
11
12
13
DESCRIPTION
PA RT
NUMBER
V12514
V12515
V13113
V12516
V12517
V12518
V12779
V12788
V03436
V03435
V02784
V13321
V03686
V02789
V12971
KEY
NO.
14
15
16
17
18
19
20
‡
‡
DESCRIPTION
Side Liner 30"
Side Liner 36"
Side Liner 42"
Side Liner 48"
Side Liner 54"
Side Liner 60"
"Best by Broan" Logo - White
"Best by Broan" Logo - Black
Thermostat Bracket
Thermostat (Heat Sentry
™
)
Lock nut # 10-32
Exhaust plate
Filter clip
Instruction Manual
Part Bag (Contains (4) Screws
#10-2"Flat head, (8) Screws
#8-3/4 T/A, (4) Nuts #10-32,
(2) Wall Anchors, (2) Washers
3/16" ID X 3/4" OD
