- 8 -
(OPTIONAL) FK260 Series
From inside the hood, attach flue to top
of hood at sides and front of hood using
#8 screws (provided).
10. INSTALL THE OPTIONAL SOFFIT CHIMNEY
HD0050
Inside top of hood
11. INSTALL BLOWER
Refer to instructions included
with blower.
Once the blower is installed,
plug the blower unit into the
female receptacle and the
power supply onto the male
connector inside the hood.
DO NOT plug the two cords
into each other.
HE0003
This range hood uses 120V, 50W
halogen lamps. (Size PAR 20)
Installation:
1. Install the lights by rotating clockwise.
2. Install chrome rings by pushing upward.
12. LIGHT BULBS
HD0055
Chrome
Ring
To Next Page
