Before installing the machine, the operator must check the work area for any devices that may malfunction because of
electromagnetic disturbances. Consider the following.
• Input and output cables, control cables, and telephone cables that are in or adjacent to the work area and the
machine.
• Radio and/or television transmitters and receivers. Computers or computer controlled equipment.
• Safety and control equipment for industrial processes. Equipment for calibration and measurement.
• Personal medical devices like pacemakers and hearing aids.
• Check the electromagnetic immunity for equipment operating in or near the work area. The operator must be sure
that all equipment in the area is compatible. This may require additional protection measures.
• The dimensions of the work area to consider will depend on the construction of the area and other activities that are
taking place.
Consider the following guidelines to reduce electromagnetic emissions from the machine.
• Connect the machine to the input supply according to this manual. If disturbances occur if may be necessary to take
additional precautions such as filtering the input supply.
• The output cables should be kept as short as possible and should be positioned together. If possible connect the
work piece to ground in order to reduce the electromagnetic emissions. The operator must check that connecting
the work piece to ground does not cause problems or unsafe operating conditions for personnel and equipment.
• Shielding of cables in the work area can reduce electromagnetic emissions. This may be necessary for special
applications.
Technical Specifications
INPUT
Input Power at Rated Output
B 151 I
2.0kW @ 100% Duty Cycle
3.5kW @ 25% Duty Cycle
B 181 I
2.5kW @ 100% Duty Cycle
4.2kW @ 30% Duty Cycle
Input Voltage
230V ± 15%
Single Phase
B 210 I
2.9kW @ 100% Duty Cycle
5.1kW @ 35% Duty Cycle
Frequency
50/60Hz
RATED OUTPUT AT 40°C
Duty Cycle
(Based on a 10 min. period)
Output Current Output Voltage
B 151 I
100%
25%
70A
120A
22.8Vdc
24.8Vdc
B 181 I
100%
30%
90A
140A
23.6Vdc
25.6Vdc
B 210 I
100%
35%
100A
160A
24.0Vdc
26.4Vdc
OUTPUT RANGE
Welding Current Range Maximum Open Circuit Voltage
B 151 I 10 – 120A
B 181 I 10 – 140A
B 210 I 10 – 160A
45Vdc (CE model)
RECOMMENDED INPUT CABLE AND FUSE SIZES
Fuse (delayed) or
Circuit Breaker (“D” characteristic) Size
Input Power Cable
Type of Plug
(Included with Machine)
B 151 I 16A 3 x 1.5mm
2
B 181 I 16A 3 x 2.5mm
2
B 210 I 16A 3 x 2.5mm
2
SCHUKO 16A / 250V
PHYSICAL DIMENSIONS
Height Width Length Weight
B 151 I 212mm 130mm 300mm 4.6kg
B 181 I 232mm 130mm 350mm 6.7kg
B 210 I 232mm 130mm 350mm 7.0kg
Operating Temperature
-10°C to +40°C
Storage Temperature
-25°C to +55°C
