12
1. Self-test button
2. Delay time control knob
3. Sensitivity control knob
4. LCD
5. Lithium batteries
6. Low voltage indicator
7. Solar cell
8. UV/IR fi lter
9. Arc sensor
MODEL
7042 LCD
VIEWING AREA (mm) 98 x 43
CARTRIDGE SIZE (mm) 110 x 90 x9
LIGHT STATE DIN 4
DARK STATE 9-13
SWITCH TIME (s) 1/1000s (EN 379)
DARK TO LIGHT (s) 0.25~1.0
POWER ON/OFF: AUTOMATIC
POWER SUPPLY: SOLAR CELL. 2 X CR2032 LITHIUM BATTERIES
UV/IR PROTECTION: DIN 13
ARC SENSORS: 2
LOW TIG AMPERAGE: 5 AMP
OPERATING TEMPERATURE: -5 °c~+55 °c
STORING TEMPERATURE: -20 °c~+70 °c
WEIGHT(g): 480
BOX SIZE (mm): 330x230x230
WELDING PROCESSES:
MMA,MIG,MAG/CO2, TIG AND PLASMA WELDING, ARC
GOUGING, PLASMA CUTTING
INSTRUCTIONS FOR USE
EN
1 2 3 4 5 6 7 8 9
