9
5. Loading Tape: (wound adhesive side in) Lift the rear cover and place the
roll of tape in the basket area so that the strip unwinds off the rear of the
roll as the leading end is brought up toward the front of the machine. Be
sure the tape is brought over the upper roller and fed toward the front of
the machine. Close the rear cover and open the front cover and proceed
to feed the tape under the tape guide. When the tape can go no further,
you have properly loaded the tape.
Insert roll in basket Feed tape over roller Feed tape under upper plate
6. Electrical Connection
a. Plug machine into 115 volt 60 Hz current only.
WARNING
FOR YOUR SAFETY all the metal parts of this machine are electrically
grounded through a 3-wire power supply cord and a 3-prong grounding
type plug which must be plugged into a 3-wire grounded type
receptacle.
If you are not sure the electrical system in your building is properly
grounded, call a licensed electrician.
b. When all connections have been made, turn on the power switch at
the left side of the machine. The pilot light will light, indicating the
machine is ready for operation.
