22
8. Storage
If you do not plan to use the device for 2 to 3 days, we recommend that you unplug it and store it thoroughly
empty, clean and dry in the original packing in a dry environment. Ensure that no objects are placed on top
of the device.
9. What if there are problems?
Problem Cause Solution
No display. The device is not connected to
mains power supply.
Connect the mains plug and switch on
the device.
No display. The device has switched itself off
due to safety reasons.
Clean and refill the device before next
use. Then switch it on again.
The device automatically
stops when dehumidifying.
The water tank is full. Empty the water tank, then start up the
device again.
The ambient temperature is below
0°C.
The ambient temperature must be
above 0°C.
The ambient temperature is above
40°C.
The ambient temperature must be
below 40°C.
10. Replacement parts and wearing parts
Replacement parts and wearing parts are available from the corresponding service address (according to
the service address list). Please state the corresponding order number.
Designation Item number and/or order number
Rear cover 163.632
Filter 163.633
Water tank 163.634
Condensate hose 163.647
11. Technical specifications LE 40
Model LE 40
Mains voltage / Power See type plate on the device
Protection class I /
IP protection class IPX0
Dimensions (L x W x H) 289 mm x 201 mm x 469 mm
Weight when empty approx. 9.7 kg
Recommended room size 20-30m²
Maximum tank capacity approx. 1.9 litres
Dehumidifying capacity approx. 12 litres/24 h (30°C room temperature / 80% relative humidity)
approx. 6 litres/24 h (27°C room temperature / 60% relative humidity)
Nominal air flow 100m³/h
Cooling agent / quantity R 134a, 120 g
Operating temperature 5°C – 35°C
Subject to errors and changes
