CA 4146 – Examples
22
Set up the microphone stations as a chain or in a loop.
The microphone stations are connected to the Extension Ports of the power supply units as a chain or in a loop.
OK
MCS-D 200 control unit
CA 4146 power supply unit
CA 4146 power supply unit
more microphone units
more microphone units
