members in the scan list, if a user presses PTT, the two-way radio will perform
transmission in the TX channel. Any channel can be used as a specified TX
channel. In addition, a user can select a selected channel.
9Priority sampling time (ms)
The time to wait before the two-way radio scans the priority channel when
setting a call. If a call is initiated in the top priority channel, scanning will not be
performed. The two-way radio will temporarily make current transmission mute
when scanning the priority channel. Increase of this interval can reduce check
times to improve the quality of currently-transmitted audio, but this also
increases the possibility of the two-way radio missing an activity in the priority
channel.
Technical specifications
GENERAL
VHF:136-174MHz
UHF:350-390MHz 400-470 MHz
32
2
6.25KHz
7.4V DC
1700mAh
12 hours
±1ppm
50 ohm
62L* 39W*113(H) mm
291g (including battery pack)
Transmitting
H: 4-5W L: 1W
4K00F1E
-36 dBm≤1GHz/-30 dBm≥1GHz
-60dB
RALCWI
Receiving
3%BER≤0.25uV
500mW
5%
-57dBm
Environmental Indicators
-2060
-30+85
MIL-STD-810C/D/E/F
