RME - RME BT - 9
D811642_03
TECHNICAL DATA
POWER REQUIREMENT: RME 200 - 260V~ 50Hz 1,5VA
RME BT 11 - 26V /~ 50/60Hz 95mA max.
PRESENCE/PULSE RELAY : 0.5A/220VAC.
RESPONSE TIME: Approximately 120ms after vehicle enters loop.
INDICATOR: LED indicators show: Power ,Detect state and Loop Fault.
DETECTOR TUNING RANGE: 15 - 1500 uH.
PROTECTION: Loop isolation transformer with lightning protection.
CONNECTOR: 11 Pin Connector on rear of unit.
DIMENSIONS: 80mm (height) X 40mm (width) X 79mm (Depth excl. connector).
TEMPERATURE: -40°C / +85°C
SWITCH SETTINGS:
INSTALLATION MANUAL ENGLISH
CH1 DIP 4 DIP 5
PERMANENT PRESENCE DETECT MODE
OFF OFF
DIRECTION LOGIC ON OFF
DET. PULSE MODE (ON DETECTION) OFF ON
UNDET. PULSE MODE (ON CLEARING) ON ON
SWITCH SETTINGS:
DIP No.
FUNCTION
ON OFF
10 EXTEND TIME
2 SEC. OFF
7,8,9 SENS 0,02% - S7/S8/S9
7,8,9 SENS 0,01% S9 S7/S8
7,8,9 SENS 0,05% S8 S7/S9
7,8,9 SENS 0,1% S8/S9 S7
7,8,9 SENS 0,2% S7 S8/S9
7,8,9 SENS 0,5% S7/S9 S8
7,8,9 SENS 1% S7/S8 S9
7,8,9 SENS 2% S7/S8/S9 -
6 FREQUENCY LOW HIGH
5 ASB ON OFF
4 FILTRO 2 SEC. OFF
3 PERMANENT PRESENCE
DETECT MODE
PULSE PRESENCE
2 PULSE MODE UNDET DET
1 PULSE TIME 1 SEC 0,2 SEC
SWITCH SETTINGS:
DIP No.
FUNCTION
ON OFF
10 EXTEND TIME
2 SEC. OFF
7,8,9 SENS 0,02% - S7/S8/S9
7,8,9 SENS 0,01% S9 S7/S8
7,8,9 SENS 0,05% S8 S7/S9
7,8,9 SENS 0,1% S8/S9 S7
7,8,9 SENS 0,2% S7 S8/S9
7,8,9 SENS 0,5% S7/S9 S8
7,8,9 SENS 1% S7/S8 S9
7,8,9 SENS 2% S7/S8/S9 -
6 FREQUENCY LOW HIGH
5 PERMANENT PRESENCE
DETECT MODE CH 1
PULSE PRESENCE
4 PULSE MODE CH 1 UNDET DET
3 PERMANENT PRESENCE
DETECT MODE CH 2
PULSE PRESENCE
2 PULSE MODE CH 2 UNDET DET
1 PULSE TIME 1 SEC 0,2 SEC
CH2 DIP 2 DIP 3
PERMANENT PRESENCE DETECT MODE
OFF OFF
DIRECTION LOGIC ON OFF
DET. PULSE MODE (ON DETECTION) OFF ON
UNDET. PULSE MODE (ON CLEARING) ON ON
RME 1: RME 2:
RME 2
