MAINTENANCE & CLEANING
• Always keep the unit clean.
• For all inquiries and spare parts ordering, please include the item number in all cases.
• Grease the guide spindle if necessary, however at least every six months. Clean the spindle
before greasing. Recommended grease: graphite grease.
SAFETY PIN
Overloading of the spindle will result in the safety pin breaking.
Whilst the drive nut will still rotate,
the spindle remains in its last position ensuring the spring remains compressed.
Replace the safety pin as described (Fig.C.5):
• Remove the handgrip from around the drive nut by
pulling away from the main unit.
• Drive out the broken pin with a drift pin.
• Align the drilling of the spindle and the drive nut
and drive in a new safety pin (5x26 mm, ISO13337).
GUARATEE
This tool carries a guarantee according to current law.
