6. Preparing the Gun for Use
Ensure the trigger is not depressed before connecting to the air supply.
Pay attention, that the operation pressure never exceeds over 8 bar.
WARNING! Ensure air supply does not exceed 8 bar. Too high a pressure will shorten the
product life and may be dangerous, causing damage and/or personal injury.
Clean air supply tank daily. Water in the air line will damage the gun and will invalidate your warranty.
Keep hoses away from heat, oil and sharp edges. Check hoses for wear and make certain that all
connections are secure.
7. Operating Instructions
WARNING! Ensure you read, understand and apply the safety instructions and follow the
manufacturer's instructions on the washing gun.
Ensure air supply is regulated to no more than 8 bar and then attach air hose to the gun. Aim the
nozzle of the gun into a safe area and depress the gun trigger to check for correct operation.
8. Maintencance
WARNING! Ensure gun is disconnected from air supply before attempting any maintenance. It is very
important to keep the gun and components clean to ensure free passage for the WASHING. After use
clean all items thoroughly with paraffin and allow drying before storage.
9. Part List
1
2
3
4
5
6
7
8
9
10
11
Gun body
Valve
Trigger pin
Trigger
Air nozzle
Nozzle
Screw cap
Fluid cover
Suction tube
Hose
Air inlet thread
1
0
11
3
4
2
9
8
6
7
5
1
