CHANGING SAW BLADE
CAUTION:
Disconnected air tool from air supply before replacing the blade or other maintenance work.
1. After opening the protective cap, loosen the adjusting screw of the saw blade by turning it with
the Allen key counter-clockwise (Fig. C).
2. Remove the old saw blade by pulling it out of the saw with your hand.
3. Insert a new saw blade completely into the saw.
4. Tighten the set screw by turning it clockwise (Fig. D).
5. Close the protective cap again.
SAWING
• Adjust the speed by turning the inner screw (Fig. A) clockwise or counterclockwise with a flat-
blade screwdriver (Fig. B) until the desired air flow is achieved.
• Press the trigger against the saw body and deactivate the safety lock with your finger.
• Stop the saw by releasing the trigger. The security lock engages automatically.
ALWAYS disconnect air supply before changing saw blades! Loosen blade set screw by turning
counter-clockwise with the included allen wrench.
Fully insert new blade into saw. Tighten set screw by turning clockwise. ALWAYS make sure the
set screw is tight on BOTH sides.
