Instruction Manual
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
Art. 4101
Rolling Work Table
WARNING
• Observe the load limit of 23 Kg (50 lbs).
• When lowering table position hold table with one hand and slowly release pressure of locking
device with other hand.
• Correct Position for table top is centered directly over longest width of wheels (as shown in fig.1).
To avoid tipping do not rotate table beyond this point.
• When positioning table, insure table locking device is secure.
• Only use the table on solid, smooth surfaces.
• When positioning table next to or over painted or valuable surface, please insure surfaces have
protective, non-scratch covers.
• Do not extend table beyond extension warning line located near table pole.
ASSEMBLY
Item Description
Qty
1 Small Pad
3
2 Large Pad
1
3 Table Top
1
4 Table Top Mounting Bolt
4
5 Spring Washer
16
6 Table Top Mounting Frame
1
7 Table Top Adjusting Screw
1
8 Table Top Base Assembly
1
9 Joining Frame
1
10 Front Wheel Frame
1
11 Joining Frame Securing Bolt
12
12 Rear Wheel Frame
1
13 Ball Bearing Wheel
4
