8
*MENU I & MENU II
Under running mode, press and hold “Set” button for
6
seconds;
Controller will display “Lc”.
Enter
3
and press
“Set” for the menu in
MENU I
Enter
9
and press “Set” for menu in
MENU II.
After you done with the setting
change, press and hold “Set” for 3 seconds to
save and exit to running mode.
MENU I:
Prompt
Name
Description
When Lc = 3, controller enters into the menu below
If SV>(SP+AL), ALM light comes up, buzzer sounds and oven stops
heating
Represents the specific control method of the relay.
Pass Key
Over-temp alarm
Control Cycle
Lc
AL
T
P Proportional Increase P reduce temperature overshooting,decrease P to allow faster heating rate.
default Value
3
0~100(5)
5
35
I Integral
Increase I to lower temperature
fluctuation
Adjusted to reduce temperature overshooting.
1~1000s
(200s)
D Differential
0~1000s
(200s)
Pb
-10~10
(0)
Ambient
adjustment
PK
Et
Hot adjustment
Timing Function
-999~999
(0)
0~2(2)
Offset the temperature difference ambient and oven when it is turn off.
Pb = temperature measured by exterior thermocouple(s)
–
temperature displayed by
controller
Offset the temperature difference between the controller and actual reading inside
the oven. (use the calibration formula in 5-2 section)
0: no timer function
1: with timer function, SV window will always display dwelling time.
2: with timer function, SV window will display dwelling time after oven temperature
reaches target temperature.
