BIANCO PUMPZ PTFINOX45S2NXT

Questions and Answers

M
Melissa BruceAug 4, 2025
Why does my BIANCO PUMPZ PTFINOX45S2NXT run but have poor pressure?
- M
  Michael CervantesAug 4, 2025
  Poor pressure in your BIANCO PUMPZ Water Pump could be due to several reasons. It might be that the flow demand is too high, or the pump isn't suited for the total head requirement. The pump itself may be worn out or damaged. Another potential cause is air entering the suction line, which reduces performance. To address this, verify that the pump is appropriate for your application, check the pump's specifications, and make sure the suction line is properly sealed.
M
Michele JosephAug 9, 2025
What to do if my BIANCO PUMPZ PTFINOX45S2NXT runs but there is no flow?
- C
  Catherine ChavezAug 9, 2025
  If your BIANCO PUMPZ Water Pump is running but not producing flow, or the flow is weak, several factors could be responsible. Check if any valves are closed, ensure there are no air leaks in the suction line (which could cause loss of prime), and verify that the water level is adequate. Blockages in the pump, suction, or discharge lines could also be the issue, as well as blocked in-line filters, if fitted. It's also possible that the piping is either too long or too small. You should check the suction and discharge isolating valves, look for leaks and seal any joins or fittings, and check water availability. Clean any filters/strainers in the system.
R
Ricky PalmerAug 14, 2025
What to do if BIANCO PUMPZ PTFINOX45S2NXT is cycling on and off?
- M
  Melissa VegaAug 14, 2025
  If your BIANCO PUMPZ Water Pump is cycling on and off, it could be due to a small water draw off or leak, a leak in the suction or discharge line, or contamination in the controller. Check for small leaks, such as from taps or the cistern, and inspect for leaks, including the suction line non-return valve.
C
Chase CruzAug 19, 2025
How to fix BIANCO PUMPZ PTFINOX45S2NXT that won’t start and makes no noise?
- S
  Steven DavisAug 19, 2025
  If your BIANCO PUMPZ Water Pump isn't starting and isn't making any noise, there could be several reasons: there might be no electricity, fuses or the RCD may have tripped, there could be an internal motor fault, the static head pressure might be greater than the cut-in setting, or the controller may have sensed a dry run and is in its auto-restart cycle. First, check the power supply and see if the power LED on the controller is lit. If fuses or the RCD have tripped, this could indicate a more serious problem. Also, ensure the static water head above the controller is less than 20m. If the controller has sensed a dry run, press the reset button.
M
Michelle RyanAug 25, 2025
What to do if BIANCO PUMPZ PTFINOX45S2NXT Water Pump doesn’t start but makes a noise?
- M
  mandymackAug 25, 2025
  If your BIANCO PUMPZ Water Pump is making noise but not starting, it could be due to the motor not being free to turn (internal jamming) or a faulty capacitor. Check if the pump can rotate freely.
N
Nancy RoweAug 29, 2025
Why does BIANCO PUMPZ PTFINOX45S2NXT run intermittently?
- F
  fryekristenAug 29, 2025
  An intermittent running BIANCO PUMPZ Water Pump may be caused by overheating and the thermal protection tripping. Make sure the water temperature is below 40 degrees Celsius and that there's enough airflow to cool the motor. Keep in mind that low voltage can also lead to motor overheating.

Summary

Introduction to Bianco Pumpz

Inox Pump Description

Corrosion resistant stainless steel housing with reinforced composite internals.

Ferro Pump Description

Cast iron housing with corrosion resistant coating and reinforced composite internals.

PTF Pump Description

Cast iron housing with corrosion resistant coating and stainless steel impeller.

Key Features of Bianco Series 2 Pumps

ISO 7010 Safety Symbols

Electrical Safety Warning

Symbol indicating warning related to electrical safety.

Intended Use Warning

Warning about consequences of use outside intended application or environmental conditions.

Mandatory Warning Symbol

Symbol representing a mandatory warning.

Disconnect Power Warning

Symbol indicating a warning to disconnect power.

Read Carefully Instruction

Symbol advising users to read instructions carefully.

General Warnings and Cautions

General Safety Precautions

Covers reading the manual, disconnection before maintenance, and qualified personnel for wiring.

Electrical Safety Precautions

Warnings about opening covers connected to supply and using qualified electricians for circuit breakers.

Appliance Usage Restrictions

Notes on use by persons with reduced capabilities and supervising children.

Motor Thermal Overload

Guidance on avoiding excessive thermal shock to the motor by limiting start cycles.

Compliance with Regulations

Ensure installation complies with all applicable local regulations.

Operational Cautions

Environmental Protection

Protect pump and controller from extreme heat, cold, rain, and moisture.

Water Quality Requirements

Pump designed for clean water; contamination can affect operation; pH range 6.5-8.5.

Unsuitable Water Types

Pump not suitable for spa or pool water.

Dry Run Protection

Running pump dry damages the mechanical seal and voids warranty.

Chemical Exposure Avoidance

Avoid exposure to corrosive liquids, gases, flammable materials, or solvents.

Qualified Personnel for Installation

Fitment and replacement must be carried out by competent, skilled, and qualified personnel.

Standards and Approvals

SAA Approvals

Accreditation by JAS-ANZ for electrical equipment safety compliance.

AS;NZ4020 Drinking Water Approval

Demonstrates compliance for products in contact with drinking water.

CE Marking

Indicates conformity with EU health, safety, and environment directives.

Technical Specifications Overview

Electrical Connections and Safety

RCD Safety Switch Requirement

Use an electrical outlet protected by an RCD safety switch with 30mA trip current.

Power Cord and Plug Specifications

Pump supplied with a 10 amp rated lead and 3 pin male power plug.

Electrical Connection Diagram

Diagram illustrating single-phase power connection with isolator, fuse, and controller.

General Installation Guidelines

Pump Location and Power Supply

Choose a location with a firm base, close to water source and power supply.

Enclosure and Environmental Protection

House pump in weather-proof, free-draining, well-vented enclosure.

Mounting and Pipework Support

Ensure secure mounting and support pipework to avoid strain.

Intake (Suction) Piping Best Practices

Pipe Sizing and Layout

Match pipe size to inlet port, keep piping short, straight, and avoid air pockets.

Servicing Access

Use unions for easy removal of pump for servicing.

Discharge Valve

Gate valve on discharge aids diagnosing system problems.

In-line Strainer;Filter

Optional strainer for water with particles; requires regular maintenance.

Boosting Mains or Connecting to Hot Water Systems

Boosting Mains Supply

Not recommended to connect directly; use an isolating (break) tank.

Mains Pressure Hot Water Systems

Fit approved Non Return Valve to hot water inlet.

Low Pressure Hot Water Systems

Fit pressure reducing valve to not exceed cylinder rating.

Water Column Limit Above Controller

Water column above controller cannot exceed 20m.

Flooded Suction Installation

Tank Isolation Valve

Fit a valve to isolate the water tank.

Suction Line Valve

Fit another valve close to the pump if the suction line is long.

Suction Line Non Return Valve

Non Return Valve in suction line is recommended.

Avoid Air Traps

Avoid pipework that could trap air.

Minimum Water Level

Ensure water level is above pump inlet for flow.

Suction Lift Installation

Foot Valve and Intake Screen

Required for suction pipes drawing upwards over 1m.

Minimum Water Level Above Intake

Ensure at least 300mm of water above the intake at all times.

Intake Screen Placement

Keep intake screen at least 100mm above tank/well bottom.

Pipework Air Traps

Avoid pipework which could trap air.

Suction Pipe Sizing Recommendation

Use chart to select correct inlet pipe size for optimal performance.

Pump Priming and Operation

Manual Priming Requirement

Pump and delivery line must be manually primed before first start.

Filling Pump and Suction Line

Fill pump body and suction line completely with clean water.

Checking Fan Rotation

Verify that the motor fan blade rotates freely.

Ensuring Inlet Submersion

Ensure pump inlet line is fully submerged and draws no air.

Power Connection and Initial Start

Connect power and start pump with a tap open.

Troubleshooting No;Low Flow

Check for issues if no water or limited flow occurs; reset controller if dry-run activated.

Testing Pump Shutoff

Restart pump and check it switches off when the tap is closed.

Warranty Terms and Conditions

Warranty Coverage and Claims

Details on product warranty, exclusions, and how to make a claim.

Consumer Guarantees

Entitlements under Australian Consumer Law and NZ Consumer Guarantees Act.

Exclusion and Limitation of Liability

White International excludes other warranties and limits liability as permitted by law.

Warranty Commencement

Warranty commences from date of purchase; proof of purchase required.

Troubleshooting Guide

Pump Wont Start, No Noise

Troubleshooting for no electricity, tripped fuses, or internal motor faults.

Pump Starts, Makes Noise, No Flow

Diagnosing issues like closed valves, air leaks, or low water level.

Pump Runs with Low Flow or Pressure

Addressing causes like excessive flow demand, blockages, or worn pumps.

Pump Cycling On;Off

Resolving intermittent operation due to leaks or air entry.

Pump Vibrates or is Noisy

Identifying causes like improper mounting, imbalance, or cavitation.

Water Leakage from Pump Center

Diagnosing leaks, typically indicating a faulty mechanical seal.
