BIFFI WGR 400 - Greasing Reduction Components

WGR – Worm Gear Reducer
Instruction and operating manual
© Copyright by BIFFI Italia. All right reserved MAN 684/Rev 5 Page 22
Picture 10
9.4 Greasing the main reduction and the epicyclical reduction
Please refer to Picture 11 and Picture 12
 Remove the reductions as explained in Par. 9.2 and 9.3
 Grease the worm screw and the two thrust ball bearings couple (Picture 11)
 Grease the gears of the epicyclical reduction (Picture 12)
(3) First thrust ball bearings couple
(4) Worm screw
(5) Second thrust ball bearings couple
(6) Gear
