Big Dipper L015 - DMX512 38 Channel description; CH1 Motor Displacement; CH2 Motor Speed; CH3 Overall dimming

DMX512 38 Channel description
CH #
Function
Description
CH 1 Motor Displacement
CH 2
Motor Speed
CH 3
Overall
dimming
R、G、B、W overall dimming，linear dimming，
from dark to bright
CH 4
Strobe
R、G、B、W Strobe，from slow to fast
CH 5
Function
choose
0--20：DMX 38 Channel control；21--70：
jumping；71--120：Shading；121--170：Pulse
transform；171--220：Running；221--240：
Sound-activated 1；241--255：Sound-activated 2
CH 6
Speed
Speed of function
，
from slow to fast
CH 7
R1 dimming
R1dimming，linear dimming，from dark to bright
CH 8
G1 dimming
G1 dimming
，
linear dimming
，
from dark to bright
CH 9 B1 dimming
B1 dimming，linear dimming，from dark to bright
CH 10
W1 dimming
W1 dimming，linear dimming，from dark to bright
CH 11 R2 dimming
R2 dimming
，
linear dimming
，
from dark to bright
CH 12
G2 dimming
G2 dimming，linear dimming，from dark to bright
CH 13
B2 dimming
B2 dimming，linear dimming，from dark to bright
CH 14 W2 dimming
W2 dimming，linear dimming，from dark to bright
CH 15
R3 dimming
R3 dimming，linear dimming，from dark to bright
CH 16 G3 dimming G3 dimming，linear dimming，from dark to bright
CH 17
B3 dimming
B3 dimming，linear dimming，from dark to bright
CH 18 W3 dimming W3 dimming，linear dimming，from dark to bright
CH 19
R4 dimming
R4 dimming，linear dimming，from dark to bright
CH 20
G4 dimming
G4 dimming，linear dimming，from dark to bright
CH 21 B4 dimming B4 dimming，linear dimming，from dark to bright
CH 22
W4 dimming
W4 dimming，linear dimming，from dark to bright
Page 3
Page 4
CH 23
R5 dimming
R5 dimming，linear dimming，from dark to bright
CH 24 G5 dimming G5 dimming，linear dimming，from dark to bright
CH 25
B5 dimming
B5 dimming，linear dimming，from dark to bright
CH 26
W5 dimming
W5 dimming，linear dimming，from dark to bright
CH 27 R6 dimming R6 dimming，linear dimming，from dark to bright
CH 28
G6 dimming
G6 dimming，linear dimming，from dark to bright
CH 29 B6 dimming B6 dimming，linear dimming，from dark to bright
CH 30
W6 dimming
W6 dimming，linear dimming，from dark to bright
CH 31
R7 dimming
R7 dimming，linear dimming，from dark to bright
CH 32 G7 dimming G7 dimming，linear dimming，from dark to bright
CH 33
B7 dimming
B7 dimming，linear dimming，from dark to bright
CH 34 W7 dimming W7 dimming，linear dimming，from dark to bright
CH 35
R8 dimming
R8 dimming，linear dimming，from dark to bright
CH 36 G8 dimming G8dimming，linear dimming，from dark to bright
CH 37
B8 dimming
B8 dimming，linear dimming，from dark to bright
CH 38
W8 dimming
W8 dimming，linear dimming，from dark to bright
