BIGASSFANS.COM
COOL-SPACE® 200
EXCEPTIONALLY
ENGINEERED
READ AND SAVE THESE INSTRUCTIONS
LISEZ ET CONSERVEZ CES INSTRUCTIONS
LEA Y GUARDE ESTAS INSTRUCCIONES
Operation and Maintenance Manual
Manuel de fonctionnement et d'entretien
Manual de operación y mantenimiento
F-EV1-1001S75V60

Questions and Answers

  • C
    Christopher CollinsSep 10, 2025
    How to fix scale and mineral buildup on Bigassfans COOL-SPACE 200 cooling media?
    • B
      Benjamin FloresSep 10, 2025
      To address scale and mineral buildup on the cooling media, drain and clean the cooler and the cooling media. Then, add 1 water treatment tablet to the reservoir.
  • M
    Margaret ManningAug 22, 2025
    What to do if my Bigassfans COOL-SPACE 200 Freezer pump motor will not run when switch is turned on?
    • M
      millerraymondAug 22, 2025
      If the pump motor doesn't run when switched on, turn the fan on to check for power. If the fan doesn't start, inspect the breaker and ensure the cord is plugged in. If the fan works, check for power to and through the pump switch when it's on. Also, ensure the cooler is filled with water, as the pump automatically shuts off if the water level is too low. Fill the water reservoir.
  • K
    Kimberly ClarkAug 25, 2025
    What to do if my Bigassfans COOL-SPACE 200 Freezer motor overheats, shuts off, and restarts several minutes later?
    • K
      Kyle SimmonsAug 25, 2025
      If the motor overheats, shuts off, and restarts, the extension cord gauge might be too small, so replace it with a heavier cord. Ensure the inlet air isn't obstructed and has at least 3 ft (0.9 m) of clearance from the wall. A faulty motor could also be the cause, so consider replacing it.
  • A
    April CraigAug 26, 2025
    What to do if my Bigassfans COOL-SPACE 200 breaker trips or fuse blows when switch is turned on?
    • D
      Debbie BrownAug 27, 2025
      If the breaker trips or the fuse blows when the switch is turned on, check the power cord length and breaker rating, referring to the cooler's amperage draw to determine the required cord gauge and circuit size. Also, check for a locked-up pump; if found, replace the pump.
  • J
    Jose HillAug 27, 2025
    Why is my Bigassfans Freezer fan will not run and makes humming sound?
    • G
      gibsonstephanieAug 28, 2025
      If the fan won't run and makes a humming sound, check the capacitor and re-center the blade hub. If the motor is stalled (will not turn by hand), replace it.
  • T
    Timothy SandersAug 29, 2025
    What to do if my Bigassfans COOL-SPACE 200 Freezer pump runs but does not pump water?
    • C
      Casey HoffmanAug 29, 2025
      If the pump runs but doesn't pump water, there might be an air lock in the outlet side of the pump; try turning it off and on to bleed it. Also, ensure the impeller is turning in the pump; if not, replace the pump.
  • J
    Julia CookSep 18, 2025
    How to fix too many dry streaks on Bigassfans Freezer pads?
    • M
      Melissa HawkinsSep 18, 2025
      If there are too many dry streaks on the pads, check for blocked holes in the drip channel. Remove and clean the tube and holes.
  • A
    Ashley PollardSep 12, 2025
    What to do if Bigassfans COOL-SPACE 200 water is leaking from the drain plug?
    • R
      Randy MitchellSep 12, 2025
      If water is leaking from the drain plug, check that the plug is tightly seated in the hole. Tighten the drain plug or replace it if necessary.
  • S
    Shannon BassSep 8, 2025
    Why is my Bigassfans Freezer floor at side of cooler wet?
    • M
      melissa84Sep 8, 2025
      If the floor beside the cooler is wet, the water inlet hose may be loose at the supply hose or at the bulkhead fitting. Tighten the connections and/or replace the hose washers.
  • M
    Mark HunterSep 5, 2025
    Why is my Bigassfans COOL-SPACE 200 water overflowing from reservoir?
    • L
      lopezcarrieSep 5, 2025
      Water overflowing from the reservoir could be due to a loose float valve hose at the bulkhead fitting or at the float valve; tighten the connections and/or replace the hose washers. High water pressure might also prevent the float valve from shutting off (120 PSI max), so reduce water pressure by adding an inline reducer. Lastly, the float valve might not be properly seated, so check all hoses for leaks.

Summary

Assembly and Setup

Installing the Casters

Instructions for attaching the mobile casters to the cooler unit.

Connecting the Water Supply

Guide for attaching a garden hose to the cooler's water inlet.

Connecting the Electrical Supply

Details on plugging the cooler into a suitable power circuit.

Operation

Operating the Cooler

Step-by-step process for filling the reservoir, starting the pump, and turning on the fan.

Maintenance and Storage

Removing the Cooling Media

Procedures for taking out the cooling pads for cleaning or replacement.

Daily Maintenance

Routine tasks performed after each use to ensure longevity and hygiene.

Periodic Maintenance

Regular checks and cleaning of components for optimal cooler performance.

Draining the Water Sump

Steps to empty and clean the reservoir based on usage frequency.

Using Water Treatment Tablets

Guidance on adding tablets to prevent mineral buildup.

Cleaning the Cooling Media

How to clean the pads to maintain their effectiveness.

Storage

Instructions for properly storing the cooler when not in use.

Maintenance Checklist

Spring Cleaning

Tasks for initial setup and cleaning at the start of the season.

Mid-Summer Checkup

Routine checks for proper operation during peak usage.

Winterize

Procedures for preparing the cooler for storage during cold seasons.

Troubleshooting

Tools Needed

List of necessary tools for troubleshooting and maintenance tasks.

Pump Troubleshooting

Solutions for common issues related to the cooler's water pump.

Water Distribution System Troubleshooting

Addresses problems with water flow and leaks.

Fan System Troubleshooting

Solutions for issues concerning the fan motor and operation.

Contact Us

Bigassfans COOL-SPACE 200 Specifications

General IconGeneral
BrandBigassfans
ModelCOOL-SPACE 200
CategoryFreezer
LanguageEnglish
