35
We recommend a stability bracket is fitted to the cooker.
The type shown in fig. 9. can be purchased from most plumbers merchants and do
it yourself (D.I.Y.) shops.
Stabilty Bracket
Wall fixing
Floor fixing
Dimension is in millimetres
3
Outline of cooker
backplate at the
engagement slot
Brackets
Existing slot in
rear of cooker
Dotted line showing the
position of cooker when fixed
Fig. 9.9
9
