SQ824
#M4081
LARN STYLE BRACKETS
24" STROKE
8k-lb LIFT CAPACITY
MEDIUM TANK ASSEMBLY
STANDARD #M26850
MANUAL OVERRIDE #M26855
7" FIXED FOOTPAD
4" OUTER TUBING
'B' BRACKETS (4")
QTY: 5 PER JACK
#M28930
'B' BRACKETS SLIDE FOR
ADJUSTABLE WIDTH
3.6" TO 5.5" BEAM
1/2" G8 HEX BOLT x 5.5" TO 6.5" LONG
1/2" G8 HEX NUT
1/2" G8 LOCKWASHER
QTY: 2 OF EACH PER JACK
7/16" G8 HEX BOLT x 1.5" LONG
7/16" G8 HEX NUT
7/16" G8 LOCKWASHER
QTY: 3 OF EACH PER JACK
7/16" G8 HEX BOLT x 1.75"
7/16" G8 HEX NUT
7/16" G8 LOCKWASHER
QTY: 4 OF EACH PER JACK
DRILL 1/2" CLEARANCE HOLE THROUGH
TRAILER FRAME BULKHEAD OR BEAM
ATTACH JACK USING TWO 1/2" BOLTS
(EITHER IN 5.5" OR 6.5" LENGTHS)
