3.5 For replacing the cup wheel, you should first take the old cup wheel down by following steps, (3.5.1) Put both ends of the Y type wrench
into holes around the edge of the diamond pad. (3.5.2) Fasten the Hexagonal wrench to the lock screw. (3.5.3
) Rotate these both wrenches towards
opposite directions. (3.5.4) Take the lock screw off.And then installing a new cup wheel by repeating above steps, you will achieve it easily.
3.5.1 Y type wrench
3.5.2 Remove the cup wheel
3.5.3 Socket head wrench
3.5.4 Install the cup wheel
Usage Instructions
English
8 www.bihuitools.com
