3
11
13
14
15
12
Echo Tone Control Volumes
To adjust Tone of Bass, Midrange, and Treble.
1
3
4
5
2
LEVEL (Echo)
Echo Delay
To adjust Music Interval tone Level.
To adjust Volume of Microphone Echo.
To adjust Delay Duration of Echo.
To adjust Repeat Volume of Echo.
Key Control Button
Echo Repeat
16
SD CARD
To insert card memory.
17
USB
To insert USB memory.
18
Play back and Recording button
: Reverse.
: To play back / Recording (Push the button for
more than 2 Second)
: Fast forwarding.
REAR PANEL
1
5
2
3
4
RM IN
+5V
GND
VOD and AUX.
AudioInput
Terminal
connection
Optical and Coaxial.
Digital AudioInput
To adjust volume of Input.
Input Level
HDMI 1. HDMI 2
HDMI Input
6
Connect with TV. (Video 1, Video 2)
HDMIOutput
8
High Level, Low Level (-11dB)
MicOutput (Vocal output)
9
Connect with Power amplifier.
PreOutput
7
MIC A
Mic Input
10
Connect with Powered sub woofer.
Sub woofer Output
11
A or B: 4 Ohms - 8 Ohms, A+B: 8 Ohms - 16 Ohms.
SpeakerOutput
13
It can be connected with
other IR receiver.
REMOTE Terminal
♭: To slow interval tone.
# : To fast interval tone.
♮: Back to original.
19
Wireless microhone indicator
It lights up at a wireless microphone (A, B) switch ON .
Power Cord Socket.
Power input AC 220 - 240V /50Hz.
9
10
To adjust Tone for Bass, Midrange and Treble.
When pushing button, Input Signal is changed
from VOD, AUX, Optical, Coaxial, HDMI 1, HDMI 2,
Blue tooth, USB/SD card.
Microphone Tone Control Volumes
Input Select Button
12
Connect with antenna.
Wireless ANT
/ REC
MIC A
MIC INPUT
DIGITAL AUDIO INPUT
AUDIO INPUT
MIC OUT
OUTPUT
AC IN
AC 220V-240V / 50Hz
FUSE 5A 250V AC
SPEAKER IMPEDANCE: A OR B: 4 - 8 OHMS
A + B: 8 - 16 OHMS
AC240V/50Hz 500W
QR CODE
WIRELESS KARAOKE AV AMPLIFIER
HDMI INPUT
HDMI OUTPUT
HDMI 2
LOW LEVEL
HI LEVEL
SUB WOOFER
PRE
SPEAKER OUTPUT
HDMI 1
WIRELESS MIC
ANT
13
3
6
7
42 8 11
9 10
1
5
12
