2
A
D 1
2
3
4
5
E
F
G
6
B
C
Parts Layout for Radio Package
Tools Required
1. Torx head screwdrivers #25 & #27
2. 3/16” Allen/hex wrench
(preferably ball end type)
3. #2 Phillips Screwdriver
4. Harley shop manual
(optional)
A video of this installation is available online:
www.youtube.com/user/biketronics
www.biketronics.com
A. Biketronics Decal
B. Adhesive Vinyl Sheet
C. Zip Ties - 2 Each
D. Mounting Blocks
(2 each & 4 - Philip head screws)
E. Biketronics Module
(BT1004 looks slightly different)
F. BT1005 Wire Harness
(BT1005 only)
G. Yellow Antenna Wire for Local
Reception
1. Radio **
2. Radio Face **
3. Radio Trim Ring **
4. Black Bezel Plate
5. Radio Cage **
(Not used - disard)
6. Radio harness w/ black
connector**
(Also available seperately)
** With radios purchased
from Biketronics
To Next Page
