Page 3 of 10
Congratulations on your RetroRadio purchase! RetroRadio ties almost any Sony in-dash AM/FM,
CD/MP3 player to your 1996 – 2011 family of Harley Electra Glides and Road Glides with handle-
bar radio controls. Even the speed sensor signal is used to automatically control the volume!
Should you have questions regarding RetroRadio, feel free to call Biketronics Inc. An advantage
of using the Sony is the ease to incorporate the newest audio devices such as USB, satellite
radio, GPS, Bluetooth or iPOD/MP3 units with the radio system at reasonable costs.
A. Adhesive Vinyl Sheet & Biketronics decal 1. Radio **
B. Yellow Antenna Wire (Local Reception) 2. Radio Face **
C. Zip Ties – 2 each 3. Radio Trim Ring **
D. Splash Cover for Radio Face (optional accessory) 4. Black Bezel Plate
E. Radio Wire Harness ** (Radio Black Connector 5. Radio Cage ** (Not Used –
and Biketronics White Connector) remove and discard)
F. Mounting Blocks (Left and Right Sides, 4 - screws)
G. Biketronics (Orange) Module
** Included with Biketronic radio.
1. Torx head screwdrivers #25 & #27 3. #2 Phillips screwdriver
2. 3/16" Allen/hex wrench (Preferably ball end type) 4. Harley shop manual (optional)
Parts Layout for Radio Package
