Kutty Folding/Unfolding
Follow these simple steps to fold your electric bike
(1) (2) (3)
1. Push the outside edge of the pedal towards the frame and twist until the folding section is parallel to
the frame.
2. Release the 'safety catch' mechanism on the stem by put up. Open the quick-release lever by pulling
away from the stem and lowering it.
3. Fold handlebars to the side of the bike frame as shown in the picture. Pay attention not to force cabling.
The cables should fall in front of or behind the stem when folded, not forced over the folding
mechanism.
(4) (5) (6)
4. Release the 'safety catch' mechanism located close to the bottom bracket by lifting it.
5. Pull on the quick release lever to unlock the frame hinge then push the lever back towards the frame to
fully clear the latch from the locking mechanism.
6. Lift the kickstand then rotate the front end of the bike until the front and rear wheels are next to each
other. The bike can now be supported by the metal stand situated under the bottom bracket.
