Bilanciai D70ES - Unpacking and Installation; Connecting Peripherals; Instrument Power On

1. Unpacking and Installation
Take instrument out of package.
Connect:
• 110/240 Vac 50/60Hz power supply
• Weighing pla tform
• Serial port RS232 (COM1)
• Serial port RS232/RS422 (COM2)
• I/O terminal (OPTIONAL)
• Ethernet port 10/100 Mbps (OPTIONAL)
• Analog output 4-20 mA, 0-10V (OPTIONAL)
Press to turn on instrument.
www.coopbilanciai.it
ON/OFF
