ITEM KD511IC KD511H KD511HS KD611
NO. Part No. Part No. Part No. Part No.
1 PRO DEBRIS BAG (service) 890023 1 890023 1 890023 1 890023 1
2 THROTTLE 850270 1 850270 1 850270 1 850270 1
3
4 NUT LOCK (1/4 - 20 ) *8160001 6 *8160001 6 *8160001 6 *8160001 6
5 SCREW CAP ( 1/4 - 20 x 1-1/2 HEX ) *8041008 4 *8041008 4 *8041008 4 *8041008 4
6 HANDLE ASS’Y (incl. items 4(5),5(5),11(2),75(2),76) 900054 1 900054 1 900054 1 900054 1
7 AXLE HEIGHT ADJUST 890389 1 890389 1 890389 1 890389 1
8 SCREW HANDLE 5/16 - 18 x 1 - 1/2 *8041030 2 *8041030 2 *8041030 2 *8041030 2
9 CLAMP CABLE 900407 2 900407 2 900407 2 900407 2
10 SCREW CAP 1/4 - 20 x 1 3/4 *8041009 1 *8041009 1 *8041009 1 *8041009 1
11 BAR BAG SUPPORT 900039 2 900039 2 900039 2 900039 2
12 DOOR EXHAUST ASS’Y (incl. item 62 ) 890148 1 890148 1 890148 1 890148 1
13 PLATE TOP ASS’Y (incl. items 14, 15, 29, 48, 57) 890402 1 890402 1 890402 1 890402 1
14 BOLT-CARRIAGE 1/4x3/4 *8024021 2 *8024021 2 *8024021 2 *8024021 2
15
16 WASHER 1/4 FC ZP *8171002 2 *8171002 2 *8171002 2 *8171002 2
17
18 BRACKET - HEIGHT ADJUSTMENT 890021 1 890021 1 890021 1 890021 1
19 PLATE UPPER HEIGHT ADJUST 890005 1 890005 1 890005 1 890005 1
20 SPRING 900136 1 900136 1 900136 1 900136 1
21 TIRE - ONLY (PER ASSY) 900507 1 900507 1 900507 1 900507 1
22 PIN - HAIR COTTER 900471 1 900471 1 900471 1 900471 1
23 CABLE HEIGHT ADJUSTMENT 890019 1 890019 1 890019 1 890019 1
24 BOLT - CARRIAGE 5/16 - 18 x 4 1/2 *8024054 4 *8024054 4 *8024054 4 *8024054 4
25
26 NUT LOCK 5/16 - 18 HEX *8160002 4 *8160002 4 *8160002 6 *8160002 4
27 HANDLE LOWER KD510 890346 1 890346 1 890346 1 890346 1
28 PLATE HANDLE SUPPORT 900933 1 900933 1 900933 2 900933 1
29 LABEL DANGER CUT FINGER 400424 2 400424 2 400424 2 400424 2
30 WASHER FLAT CUT 5/16 *8171003 2 *8171003 2 *8171003 2 *8171003 2
31
32 NUT LOCK 5/16 - 18 THIN HT. *8161041 2 *8161041 2 *8161041 4 *8161041 2
33 GRIP HANDLE 400570 2 400570 2 400570 2 400570 2
34 WHEEL ASS’Y (incl. items 21) 900509 4 900509 4 900509 4 900509 4
35 WASHER 0.75 “C” 900997 0 -1 900997 0 -1 900997 0 -1 900997 0 -1
36
37 SCREW SM 1/4x3/4 TYPE A - - - - *8122082 4 - -
38 PLATE SKID (incl. items 54) - - - - 890413 1 - -
39
40 SCREW CAP 1/4 - 20 x 1 - 1/4 *8041007 4 *8041007 4 *8041007 4 *8041007 4
41
42 SCREW SELF TAPPING 10 - 24 x 1/2 *8123086 1 *8123086 1 *8123086 1 *8123086 1
43 NOZZLE MAINFRAME ASS’Y (incl. one of items 29,44,42) 890391 1 890391 1 890391 1 890391 1
44 PLUG 900146 1 900146 1 900146 1 900146 1
45
46
47 IMPELLER ASS’Y (incl. items 46, 59 ) 900215 1 900003 1 900003 1 900215 1
48 SCREW CAP 1/4-20 X 2 8041010 1 8041010 1 8041010 1 8041010 1
49 KEY 900162 2 900162 2 900162 2 900162 2
50 WASHER LOCK 3/8 TWISTED TOOTH 400502 1 400502 1 400502 1 400502 1
51 SCREW CAP 3/8 -24 x 1 (HARDENED)(TORQ.50 FT-LBS)(68N.m) 900154 1 900154 1 900154 1 900154 1
52 HOUSING ASS’Y (incl. items 12, 14, 15, 16, 66) 890371-S 1 890371-S 1 890417-S 1 890371-S 1
53 ENGINE HONDA 5.5 H.P. GXV160 KN12 - - 900615 1 900615 1 - -
ENGINE BRIGGS & STRATTON 5 H.P. QUANTUM IC 890403 1 - - - -
ENGINE BRIGGS & STRATTON 6.0 HP INTEK EDGE 890387 1
54 BOLT CARRIAGE 5/16-18x3/4" - - - - 8024039 2 - -
55 LINE PVC - - - - 900732 1 - -
56 SCREW CAP 3/8 - 1-1/2 TAPTITE 890408 3 - - - - 890408 3
SCREW CAP 5/16 - 24 x 1" - - 400164 3 400164 3 - -
57 SCREW CAP 1/4 - 20 x 1/2 HWH 890359 15 890359 15 890359 15 890359 15
58 WASHER FLAT 1/2 SAE *8172011 4 *8172011 4 *8172011 4 *8172011 4
59 SCREW SOCKET HD. 5/16 - 18 x 3/4 GR. 8
60 HGT ADJUST ASSY (INCL. ITEMS 18, 20, 22, 23) 890013 1 890013 1 890013 1 890013 1
61 1/2-13 CAP NUT NP W/PATCH 890530 4 890530 4 890530 4 890530 4
62 LABEL DANGER FLYING MATERIAL 810736 1 810736 1 810736 1 810736 1
63 LABEL DO NOT FILL WHEN ENGINE IS HOT 400268 1 400268 1 400268 1 400268 1
64 CONNECTOR BAG QUICK 890176 1 890176 1 890176 1 890176 1
65 LABEL READ OWNER'S MANUAL 890301 1 890301 1 890301 1 890301 1
66 LABEL EAR/EYE BREATHING 890254 1 890254 1 890254 1 890254 1
