STEP 56 - FORT ASSEMBLY
ROPE CLAMP KIT
(x6)
A6P00508
7'-7 1/4" ROPE
(x1)
A6P00617
2
i
n
[
5
0
m
m
]
8 3/8 in
[212 mm]
ROPE CLAMP
SPACING
MINIMUM 2 INCHES [50mm] OF
ROPE
OUT OF ROPE CLAMP
26 3/8 in
[668 mm]
