Bilt Backyard Discovery WHISPERING POINT - Page 104

STEP 57 - FORT ASSEMBLY
QTY
PART NUMBER DESCRIPTION
2 H100468 BOLT WH 5/16x1 BLK
2
H100379
T-NUT 5/16 BLK
4 H100471 LAG SCREW WH 5/16x1 1/2 BLK
TIP:
INSTALL T-NUTS IN WOOD FIRST
249 (x3)
HAND GRIP METAL GREY 381 c/c
379 (x2)
T-NUT - 5/16"
468 (x2)
BOLT - 1"
471 (x4)
LAG SCREW - 1 1/2"
HAND GRIP METAL GREY 381 C/C
(x3)
A4M02249
104
