Bilt Backyard Discovery WHISPERING POINT - Page 24

STEP 3 - ROPE WALL
QTY
PART NUMBER DESCRIPTION
14 H100380 SCREW PFH 8x1-1/8" BLK
BACK VIEW
CLEAT - W4L18229
5/8"x2 3/8"x50 3/4" (16x60x1289)
N01
(x1)
FLUSH TOPS
7 7/8 in
[201 mm]
BOTH SIDES
N01 (x1)
380 (x14)
SCREW - 1 1/8"
T
O
P
6 5/8 in
[167 mm]
1 3/4 in
[46 mm]
24
