Bilt Backyard Discovery WHISPERING POINT - Page 23

STEP 2 - ROPE WALL
LEFT RAIL - W4L18224
1 3/8"x3 3/8"x57 3/8" (36x86x1456)
E07
(x1)
RIGHT RAIL - W4L18225
1 3/8"x3 3/8"x57 3/8" (36x86x1456)
E08
(x1)
201 (x12)
SCREW - 2 1/2"
QTY
PART NUMBER DESCRIPTION
12 H100201 SCREW PFH 8x2 1/2 BLK
HOLES OFFSET
OUTWARDS
FLUSH SIDES
FLUSH TOPS
E08 (x1)
E07 (x1)
TOP VIEW
23
