STEP 4 - CROWS NEST DECK ASSEMBLY
QTY
PART NUMBER DESCRIPTION
2
H100387 SCREW PFH 8x1-1/4" BLK
387 (x2)
SCREW - 1 1/4"
H19 (x1)
7 5/8 in
[193 mm]
11 3/4 in
[300 mm]
15 1/2 in
[394 mm]
12 7/8 in
[327 mm]
CROWS NEST FLOOR SUPPORT - W4L18294
1"x3 3/8"x24 1/8" (24x86x614)
H19
(x1)
NOTE:
MARK LOCATIONS SHOWN. USING A
3/16" (5 mm) DRILL BIT, DRILL (2)
PILOT HOLES.
To Next Page
