Bilt Backyard Discovery WHISPERING POINT - Page 36

STEP 5 - LADDER & ROCK WALL ASSEMBLY
QTY
PART NUMBER DESCRIPTION
66 H100200 SCREW PFH 8x1-1/2" BLK
M15 RA (x2)
M16 DA (x3)
M15 LA (x2)
START HERE
FLUSH TOPS
SIDE VIEW
M13 (x9)
N04 (x1)
200 (x66)
SCREW - 1 1/2"
M13 (x1)
M15 LA (x1)
M13 (x1)
M16 DA (x1)
M13 (x1)
M15 RA (x1)
M13 (x1)
M16 DA (x1)
M13 (x1)
M15 LA (x1)
M13 (x1)
M16 DA (x1)
M13 (x1)
M15 RA (x1)
M13 (x1)
M13 (x1)
N04 (x1)
BOARD PLACEMENT
FRONT VIEW
ROCK BOARD - W4L18314
5/8"x3 3/8"x25 3/4" (16x86x655)
M13
(x9)
ROCK WALL BOARD - W4L18313
5/8"x1 5/8"x25 3/4" (16x40x655)
N04
(x1)
36
