Wood Components (Not to Scale)
Owner's Manual - Parts Identification
FRONT ARCHED RAIL - W4L18270
1 3/8"x5 1/4"x59 1/2" (36x134x1510)
D01
(x1)
ANGLE BRACE - W4L18261
1 7/16"x3 3/8"x17 1/2" (36x86x444)
E01
(x8)
WALL BOARD - W4L18287
1 3/8"x3 3/8"x54 3/8" (36x86x1382)
E02
(x2)
CROWS NEST FLOOR RAIL - W4L18291
1 3/8"x3 3/8"x33 1/4" (36x86x846)
E03
(x2)
CROWS NEST DECK BRACE - W4L18292
1 7/16"x3 3/8"x10 7/8" (36x86x276)
E04
(x2)
LEFT RAIL - W4L18224
1 3/8"x3 3/8"x57 3/8" (36x86x1456)
E07
(x1)
RIGHT RAIL - W4L18225
1 3/8"x3 3/8"x57 3/8" (36x86x1456)
E08
(x1)
UPRIGHT - W4L18318
1 3/8"x2 3/4"x56 7/8" (36x70x1444)
E09
(x2)
RIGHT UPRIGHT - W4L18312
1 3/8"x3 3/8"x57 1/8" (36x86x1450)
E10
(x1)
MIDDLE UPRIGHT - W4L18308
1 3/8"x3 3/8"x57 1/8" (36x86x1450)
E11
(x1)
LEFT UPRIGHT - W4L18307
1 3/8"x3 3/8"x57 1/8" (36x86x1450)
E12
(x1)
END SUPPORT - W4L18220
1 1/2"x3 1/2"x44" (36x86x1120)
E79
(x1)
