STEP 10 - FORT ASSEMBLY
M03 (x1)
M02 (x2)
K01 (x1)
200 (x22)
SCREW - 1 1/2"
QTY
PART NUMBER DESCRIPTION
22
H100200 SCREW PFH 8x1 1/2 BLK
COUNTERTOP BOARD - W4L18254
5/8"x5 1/4"x57" (16x134x1449)
K01
(x1)
COUNTERTOP BOARD - W4L18252
5/8"x3 3/8"x23 7/8" (16x86x605)
M02
(x2)
COUNTERTOP BOARD - W4L18253
5/8"x3"x51 1/8" (16x76x1297)
M03
(x1)
NOTE COUNTER BORES UPWARD
WHEN INSTALLED
To Next Page
