Wood Components (Not to Scale)
Owner's Manual - Parts Identification
WALL RAIL - W4L18272
1"x5 1/4"x40" (24x134x1017)
G09
(x2)
GROUND BOARD - W4L18218
1"x5 1/4"x75 1/4" (24x134x1912)
G50
(x1)
COUNTERTOP RAIL - W4L18240
1"x3 3/8"x59" (24x86x1498)
H01
(x1)
WALL RAIL - W4L18245
1"x3 3/8"x40" (24x86x1017)
H02
(x1)
WALL UPRIGHT - W4L18246
1"x3 3/8"x49" (24x86x1244)
H03
(x1)
WALL RAIL - W4L18247
1"x3 3/8"x21 3/4" (24x86x551)
H04
(x1)
FLOOR JOIST - W4L18259
1"x3 3/8"x57 1/8" (24x86x1450)
H05
(x1)
FLOOR BLOCK - W4L18260
1"x3"x3 3/8" (24x76x86)
H06
(x4)
WALL RAIL - W4L18264
1"x3 3/8"x40" (24x86x1017)
H07
(x2)
WALL RAIL - W4L18269
1"x3 3/8"x40" (24x86x1017)
H08
(x1)
