STEP 24 - FORT ASSEMBLY
TIP:
INSTALL T-NUTS IN WOOD FIRST
379 (x8)
T-NUT - 5/16"
198 (x8)
WASHER - 8x19
415 (x4)
BOLT - 3 3/4"
H07 (x1)
M07 (x1)
QTY
PART NUMBER DESCRIPTION
8 H100198 WASHER LOCK EXT 8x19 BLK
8 H100379
T-NUT 5/16 BLK
4 H100415 BOLT WH 5/16x3 3/4 BLK
4
H100503
BOLT WH 5/16x3 1/2 BLK
WALL RAIL - W4L18280
5/8"x3 3/8"x40" (16x86x1017)
M07
(x1)
WALL RAIL - W4L18264
1"x3 3/8"x40" (24x86x1017)
H07
(x1)
503 (x4)
BOLT - 3 1/2"
