Bilt Backyard Discovery WHISPERING POINT - Page 86

STEP 40 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
2
H100205
BOLT WH 5/16x2 1/4 BLK
2 H100468 BOLT WH 5/16x1 BLK
2
H100198
WASHER LOCK EXT 8x19 BLK
4 H100379 T-NUT 5/16 BLK
2 H100471 LAG SCREW WH 5/16x1 1/2 BLK
TIP:
INSTALL T-NUTS IN WOOD FIRST
205 (x2)
BOLT - 2 1/4"
198 (x2)
WASHER - 8x19
379 (x4)
T-NUT - 5/16"
471 (x2)
LAG SCREW - 1 1/2"
468 (x2)
BOLT - 1"
1047 (x2)
L BRACKET 2.5x38x55x55
H24 (x2)
L BRACKET 2.5x38x55x55
(x2)
A4M01047
CROW
S NEST WALL RAIL - W4L18304
1"x3 3/8"x11 1/8" (24x86x282)
H24
(x2)
1 1/8 in
[30 mm]
1 1/8 in
[30 mm]
