STEP 49 - FORT ASSEMBLY
RP2 (x1)
RP2 (x1)
391 (x8)
SCREW - 2"
QTY
PART NUMBER DESCRIPTION
8 H100391 SCREW PFH 8x2 BLK
RP2
(x2)
ROOF PANEL - W2A03947
1 5/8"x15 5/8"x59 3/8" (42x396x1241)
95
