STEP 48 - FORT ASSEMBLY
QTY
PART NUMBER DESCRIPTION
8 H100391 SCREW PFH 8x2 BLK
RP1 (x1)
RP1 (x1)
391 (x8)
SCREW - 2"
RP1
(x2)
PEAK ROOF PANEL - W2A03948
1 5/
8"x13 3/8"x48 7/8" (42x341x1241)
94
