ASSEMBLY INSTRUCTIONS
STEP 3
Align holes in SHELF (C) with bottom of LEG (D),
making sure that Shelf Lip is facing TUB (A).
Screw LOCKING CASTER (K) into bottom of LEG
(D), securing SHELF (C) in between. Make sure
LOCKING CASTERS (K) are installed on the same
side. Screw NON-LOCKING CASTER (L) into
bottom of LEG (D), securing SHELF (C) in
between. Repeat for the other NON-LOCKING
CASTER (L).
Tighten CASTERS (K, L) with the provided
WRENCH (M).
Use provided caster wrench to tighten
completely. Failure to do as instructed could
result in caster stem breaking.
L
M
K
C
D
STEP 4
Turn the Cooler right side up.
Attach BOTTLE OPENER (I) to TUB (A) using
SMALL SCREWS (E).
Attach CAP CATCHER (H) to TUB (A) by
sliding it down on metal notch.
H
E
I
3
© 2020 TRINITY - 800.985.5506
