Bilt Trinity TXK-0806 - Final Assembly Steps; Step 5: Install Drain Plug; Step 6: Place Lid

12 pages

To Next Page

To Previous Page

ASSEMBLY INSTRUCTIONS

STEP 5

Unscrew DRAIN PLUG (J) assembly. Insert

DRAIN PLUG (J) through the opening in TUB

(A) from the inside. Make sure the rubber

seal is on the inside of TUB (A).

From the outside, slide the Washer on first,

then the second Washer with Chain, and

then screw on the Nut. Be sure not to

overtighten. Once DRAIN PLUG (J) is in place,

screw on the Cap.

Outside the tub

Inside the tub

STEP 6

Set LID (B) on top of TUB (A).

Clean the inside of Cooler thoroughly

before use.
