Attaching Bassinet Fabric
Parts Needed:
Drape the Bassinet Fabric (C) over the support frame,
making sure that the control unit and Canopy holes are
lined up Figure 1.
Secure the fabric by snapping all snaps located on the
fabric. There will be 10 snaps around the top Figure 2
and 1 snap on each side at the bottom. Note: Please
remove the frame from base to attach snaps on
bottom of Mattress Support.
To secure the fabric ends, gently stretch them
over the Mattress Support.
Figure 3.
Once fabric is attached, insert the Canopy
into the Canopy holes. Canopy release tabs
should face out. Make sure Canopy snaps
into place on Canopy holder located on
the bassinet frame. Figure 4.
(C) Bassinet Fabric (E) Canopy (G) Mattress Pad
2
3
4
(C)
8
(C)
