IMPORTANT: Do not install any fasteners until instructed!
FRONT GRID ASSEMBLY
REAR GRID ASSEMBLY
SLIDERAIL ASSEMBLY
Step 1
Parts Needed:
4 of #1 2 of #2
2 of #3
Parts Needed:
4 of #1 2 of #2
1 of #4 1 of #5
4 Horizontal Crossbars (#1) inserted through
2 Center Verticals (#2)
Tip: When installing second Center Vertical, stand
assembly with Horizontal Crossbars placed on floor
and push down second Center Vertical to Alignment
Dimples.
1 Left Front Corner Vertical (#4) and 1 Right Front
Corner Vertical (#5) Placed on Horizontal
Crossbars
4 Horizontal Crossbars (#1) inserted through
2 Center Verticals (#2)
Tip: When installing second Center Vertical, stand
assembly with Horizontal Crossbars placed on floor
and push down second Center Vertical to Alignment
Dimples.
2 Left and Right Rear Corner Verticals (#3)
Placed on Horizontal Crossbars
12 Horizontal Sliderails (#8) inserted in Rear Grid
Tip: If necessary tap Horizontal Sliderails to be
sure Sliderails are fully inserted
Fastening Horizontal Sliderails (#8) in Rear Grid
using 12 - #06 x 1/2" Fastening Screws (#1)
Note: Start at top row and work down
Use only one fastener - Bottom Hole Only
All Horizontal Sliderails fastened to Rear Grid
Note: Fastener in Bottom Hole Only
Top
Step 2
#1
#1
#1
#1
#2
#2
Short side down
Holes down
Step 3
Top
Alignment Dimples Down
Holes down
Warning Labels
#4
#5
Step 1
#1
#2
#3
Step 2
#1
#2
#1
#1
#1
#2
Short side down
Holes up
Step 3
Alignment Dimples
#3
#3
Step 1
#8 #8 #8
#8 #8 #8
#8 #8 #8
#8 #8 #8
Short side down
Step 2
Top
Short side down
Fasten from Bottom Hole Only
Tilt Sliderails Forward
Step 3
Numbers in BOLD indicate item number from Parts/Fastener Lists.
#1
#2
#4
#5
Alignment Dimples
Alignment Dimples
To Next Page
