4
LVP180914 Rev. D
www.bindicator.com
TECHNICAL SPECIFICATIONS: ROD CONFIGURATIONS
FUNCTIONAL
Power Requirements Universal (± 10%), 120-240 VAC 50/60 Hz or 24-48 VDC
Power Consumption 4 W AC; 4 W DC
Fuse
Slow Blow, 0.5 A 300 V (Not User Serviceable)
Operating Temperature
Electronics: Ordinary Location -40° to 158° F (-40° to 70° C)
Electronics: Hazardous Location -4° to 158° F (-20° to 70° C)
Electronics: Hazardous Location -T -40° to 158° F (-40° to 70° C)
Process: Standard Temperature -22° to 203° F (-30° to 95° C)
Process: High Temperature -22° to 320° F (-30° to 160° C)
Outputs
Main Relay 8 A DPDT @ 240 VAC or 30 VDC (resistive)
Auxiliary Relay - ADVANCED ONLY 0.46 A SPDT @ 150 VAC or 1 A @ 30 VDC
PERFORMANCE
Pressure Rating
150 psi (10.5 kg/cm
2
) with
3
/
4
” NPT; 50 psi (3.5 kg/cm
2
) with 1
1
/
4
” NPT
Time Delay - STANDARD
Field Adjustable; Up to 6 seconds
Time Delay - ADVANCED
Field Adjustable; Up to 150 seconds
Fail Safe Field Selectable; high/low level
Sensitivity - STANDARD
Minimum 6 lbs/ ft
3
(96 kg/m
3
); Field Adjustable
Sensitivity - ADVANCED
Minimum 3 lbs/ft
3
(48 kg/m
3
); Field Adjustable
Remote Distance 50 ft. (15 m) Max
PHYSICAL
Enclosure Material
Powder or Epoxy Coated Aluminum or 304 SS
Process Fitting
NPT
3
/
4
”, 1
1
/
4
” ,1
1
/
2
”
BSP R 1
1
/
4
” ,1
1
/
2
”
BSP G 1
1
/
4
” ,1
1
/
2
”
Rod Material 316 Stainless Steel
Dual Conduit Entry
3
/
4
” NPT or M20 x 1.5
Mounting Plate Material Mild Steel, 304 Stainless Steel
Extended Pipe Material
316 Stainless Steel
Shipping Weight Integral, non-extended 10 lb (4.5 kg)
Pollution Degree 2
Installation Category II
Altitude 6,562 ft (2,000 m)
APPROVALS & RATINGS
UL:
Ordinary Location Type 4X; IP66 (US and Canada)
Hazardous Location, Type 4X
Explosion Proof, Class I, Div 1, Groups C, D (US Only)
Dust Ignition Proof, Class II, Div 1, Groups E, F, G (US and Canada)
CE
Electromagnetic Compatibility Directive
Low Voltage Directive
