BINO Hampton Cot bed - Cot Mode Assembly Steps; Step 1: Initial Side Attachment

COT MODE ASSEMBLY
1.
Height 3
Height 1
Height 2
Height 3
1
1
3
X4
1
Bolt (M6x35mm) X4
Not to tighten the screws until
the both cot sides assembled.
C
C
H
Plastic Washer (Dia.12x1mm) X4
H
H
Make sure to face base slats upwards
(see label
'THIS SIDE UP')
Turning base the wrong way will weaken
its structure.
