Bio Smart Technologies KF-25GW - Indoor and Outdoor Units Outline

Page 5
©2020 BioSmart Technologies
Please Note:
• Power : 'Power' lamp lights up during Cooling Operation
Plasma filter
Here is a brief introduction of the indoor and outdoor units. Please see the information specific to your
indoor unit type.
Product Introduction
Indoor Units
Air intake vents
Air outlet vents
Connecting
wires
Refrigerant pipes
Drain hose
Base plate
Outdoor Unit
Operation Indication Lamps
Operation lamp
Signal Receiver
ON/OFF
button
Air inlet
Air filter
Front grille
Vertical louver
Allergy free filter (Optional)
Air outlet
Horizontal vane
Triple filter
• Timer : 'Timer' lamp lights up during Timer Operation
The Indoor unit exploded view is for your reference only.
The actual structure and design of indoor unit may vary
depending on the indoor designs chosen by you.
5
INDOOR AND OUTDOOR UNIT 'S OUTLINE
Indoor and Outdoor Unit’s Outline
