KTY81-110 Buffer Sensor TOP (Switch-on Tempera- ture)
KTY81-110 Buffer Sensor BOTTOM (Switch-off Temperature)
Buffer Charging Pump
Internal module 1 recognised
Allocation 1: Buffer: 1
Allocation 2:
Allocation 3:
Connector View
X8
Pin
1 L Pump Buffer
N
PE
Phase Pump Buffer
Neutral Wire
Ground Wire
2
3
4
Sign
Function
X8
Pin 1Pin 1
Connector View
X11
Pin
1Temp
GND
KTX 81-110
PIN 2
2
3
Sign
Function
Pin 1Pin 1

