2. Check each handle of the manipulation system (throttle switch, clutch, shifting bar
and reversing bar) to see whether they can move freely or not. If they are out of the
right positions, make them at the right positions.
3. Pull shift bar of the gear-box to the neutral position.
4. Refilling the engine oil
① Refill the SAE10W-40 lubricant into the crankcase
of
the diesel engine. See Figure 9 for details.
② Make the whole machine stable and horizontal, and
refilling 20#lubricant engine oil into the gear-box from
oil
hole at the top of the gear-box .when check the oil level,
put
the oil dipstick into the oil .(Note: not to turn the
dipstick around), the oil level should be between the
two limits of the
oil dipstick. (refer to figure 8)
① Knock down the lower cover of the air cleaner, refill about 0.1 litre 20# engine oil
into the air cleaner.
② Select the appropriate lubricant for the diesel engine according to the environmental
temperature. (See figure 9)
4. Refill 0# or
-10# or -20# light diesel into the diesel engine.(See the instruction manual of
the diesel engine for details)
Note: do not exceed the mark when refilling.
5. Make pre-starting preparations according to the instruction manual.
Entrance of lubricant:
Fill in machine oil from oil month when diesel engine
is placed level, and checking the oil level only needs
a poke by dipstick rather than a rotation of dipstick
